38. FLASH TANK DIMENTIONS






D B Jambhale

Consuting Sugar Technologist,

former Technical adviser, VSI PUne,

Pune Maharashtra India,


Flash tank for treated juice:

The treated juice generally being heated above 103°C and if it send directly to the clarifier as it is opened to atmosphere flashing or self evaporation starts and vapor bubbles that are evolved. These vapour bubbles pass upward and disturb the precipitate. Therefore the settling mud by gravity gets disturbed.

 Therefore before sending the juice to clarifiers it is passed through a flash tank. In the flash tank the flashing effects occurs rapidly due to whirling velocity of the juice in the flash tank and the temperature of the juice comes down below the boiling point of the juice. Then the juice is send to the clarifier at a slow rate.  Now in some factories heating of the juice is done up to 97-99°C only. In such case flashing of the juice does not occur.

Fig. 1 -  flash tank


Fig. 2 -  flash tank



Flash tank size:

We will calculate the flash tank inlet outlet diameter and tank size for a 5000 TCD (230 tch) plant here under

Assumptions:

Crushing rate  TCH

230

mixed juice % cane

110

Mixed juice quantity mt/hr

253

Filtrate return  (17%) mt/hr

39

Total Juice  quantity mt/hr

292

Juice density at 99°C

1.02

Juice volume  m3/hr

286.3

Juice volume  m3/sec

0.080

 Flash tank juice inlet pipe diameter:

In calculating the inlet pipe diameter the velocity of the juice is assumed as 1.5 m/sec. The diameter can be calculate by the following formula

      p D2

                            V         =   --------------  X  v

                                                     4

Where

                  V   =  Volume of juice flow (m3/sec)

                                 D   =  Diameter of the inlet pipe

                                  n   =  Velocity of juice (m/sec.)

Putting the value of V and v

      3.142 D2

                                   0.080 =   --------------   X   1.50

                                                         4

Solving the above equation we get D = 0.261 m.

The standard pipelines available are of sizes 10” or `12” in diameter. Considering higher crushing rate 12” diameter pipeline can be used.

Flash tank dimensions:

                The flash tank volume should be about 6 m3/100 tch for venting out vapours. For as 500 tcd (230 tch) plant it should be 13.8 m3 say 14 m3.  Now considering height to diameter ratio of the tank as 1.35 we will calculate height and diameter of the tank.



      p D2

                             V         =   --------------  X  h

                                                    4

Where

                  V   =  Volume of flash tank

                                D   =  Diameter of of the flash tank

                                h   =   Height of flash tank = 1.35D

Putting the value of V and v

      3.142 D2

                                14.0  =   ------------------ X 1.35 D

                                                      4

                                                   14.0 X 4

Or       D3  =  ---------------------------------

                                3.142 X 1.35



Solving the above equation we get D = 2.37  or say 2.40 m.

Thus the diameter of the flash tank will be 2.40 m and height will be 3.24 m.

Outlet pipe diameter:

The velocity of the juice pass from flash tank to clarifier through a U siphon should be around 0.5 m/sec.  so that the floc formed will not be distrurbed. Therefore considering the juice velocity 0.5m/sec. we will calculate the diameter of the outlet and siphon.

                      p D2

                                             V         =   --------------  X  v

                                                                    4

Where

                  V   =  Volume of juice flow (m3/sec)

                                D   =  Diameter of the inlet pipe

                               n   =  Velocity of juice (m/sec.)

Putting the value of V and v

      3.142 D2

                                0.080  =    --------------      X 0.50

                                                      4

Solving the above equation we get D = 0.450 m.

Thus the diameter of the flash tank outlet and the siphon will be 0.45 m.



Thursday, 24 June 2021

36. STEAM RATING CHART FOR TURBINES





D B Jambhale Consulting Sugar Technologist
Pune  Maharashtra, Inida,


STEAM  RATING  CHART  FOR  TURBINES

Table I



Sr.

No

Turbine

Inlet Pr.

Temp



Exhaust

Pr.

Steam Rating  at Turbine Efficiency

(Kg/KWH)




Kg/cm2g

0C

Kg/cm2g

40%

Ex.T0c

45%

Ex.T 0c

50%



















1

20

320

1.0

18.78

203

16.67

191

15.00

2

30

375

1.0

15.39

234

13.68

220

12.31

3

42

415

1.0

13.41

253

11.92

237

10.73

4

42

440

1.0

12.92

277

11.48

260

10.33

5

42

480

1.0

12.17

314

10.82

296

9.74

6

62

480

1.0

11.33

292

10.08

272

9.07

7

62

510

1.0

10.86

320

9.65

299

8.69

8

86

510

1.0

10.34

299

9.19

277

8.27

9

42

415

7.0

21.41

310

19.03

300

17.12

10

42

440

7.0

20.50

334

18.22

324

16.40

11

42

480

7.0

19.21

373

17.07

361

15.36

12

62

480

7.0

16.59

347

14.75

334

13.27

13

62

510

7.0

15.80

376

14.07

362

12.65

14

86

510

7.0

14.40

353

12.80

338

11.52

15

42

480

0.1  (a)

7.66

223

6.80

192

6.12

16

62

480

0.1  (a)

7.40

202

6.58

171

5.92

17

87

510

0.1  (a)

6.99

210

6.21

177

5.59

18

20

320

3.5

26.63

235

23.67

223

21.30

19

20

370

3.5

24.23

284

21.53

275

19.38

20

32

370

3.5

20.00

258

17.78

247

16.00

21

32

430

3.5

18.00

315

16.00

302

14.40

22

42

430

3.5

16.52

299

14.69

286

13.22

23

42

470

3.5

15.47

337

13.75

322

12.37

24

62

470

3.5

14.0

313

12.44

297

11.20
